1972 Chevelle Protect-O-Plate Warranty Card

Decode your Protect-O-Plate Warranty card

I have more examples but only list a few examples on this page. If you request help with yours, contact me and I'll be glad to answer any questions you have. Include a photo of the Protect-O-Plate as plants often deviate during the model year.

You'll notice some plants used a three letter engine suffix code while some used a two letter code; Arlington even used both. All examples, so far, also used a three letter suffix code on the rear end axle ratio code.

You'll also notice that some plants code the rear end with the assembly plant first followed by the rear axle code and some will code the rear axle code first followed by the assembly plant.

VIN identification changed in 1972 in a number of ways.
>> The series was changed from a two-digit number to a single letter.
>> The engine size is now identified in the VIN.

[ Arlington ] | [ Baltimore ] | [ Kansas City ] | [ Van Nuys ] | [ Oshawa ]

CHEVELLESTUFF  All Rights Reserved

1st line:
1D37U2511476 ~ VIN
1D37 ~ Chevrolet (1), Malibu (D), 2-door sport coupe (37)
U - 402cid V8 4-bbl (LS3)
2 ~ Model Year of Production: 1972
R ~ Final Assembly Plant: Arlington, TX.
511476 ~ Sequence Assembly Number, 11,476th 1972 Chevelle at Arlington, TX.

2nd line:
T0825CTB ~ Engine Code: Tonawanda Engine Plant (T) ~ August 25 (0825) ~ 402/240hp w/TH400 (CTB)
2D275 ~ Transmission Code: Year, 1972 (2), Turbo Hydra-Matic 400 engine code 402~240hp (D), October 1 (275*)

3rd line:
CKD2742 ~ Rear Axle Number: Buffalo (C), 2.73:1 ratio (KD), September 30 (274*), and night shift (2).
C ~ Carburetor Source: Carter

Options

11331
GHIJKLM

G-1 ~ Power steering [RPO N40]
H-1 ~ Power brakes [RPO J50]
I-3 ~ Radio [RPO U63 or U69 or U79]
J-3 ~ Disc Brakes [RPO J52]
K-1 ~ Air Conditioning [RPO C60]

J ~ Vehicle Build Month: October

Owner/dealer info: Original owner's name/address removed for obvious privacy reasons.


CHEVELLESTUFF  All Rights Reserved

1st line:
1D37W2573526 ~ VIN
1D37 ~ Chevrolet (1), Malibu (D), 2-door sport coupe (37)
W - 454cid V8 4-bbl (LS5)
2 ~ Model Year of Production: 1972
R ~ Final Assembly Plant: Arlington, TX.
573526 ~ Sequence Assembly Number, 73,526th 1972 Chevelle at Arlington, TX.

2nd line:
T0413CRX ~ Engine Code: Tonawanda Engine Plant (T) ~ April 13 (0413) ~ 454/270hp w/Manual & A.I.R. (CTX)
P2D03 ~ Transmission Code: Muncie (p), Year, 1972 (2), April 3 (D03)

3rd line:
CRV0802 ~ Rear Axle Number: Buffalo (C), Positraction 3.31:1 ratio (RV), August 02 (0802)
C ~ Carburetor Source: Carter

Options

1133
GHIJKLM

G-1 ~ Power steering [RPO N40]
H-1 ~ Power brakes [RPO J50]
I-3 ~ Radio [RPO U63 or U69 or U79]
J-3 ~ Disc Brakes [RPO J52]

D ~ Vehicle Build Month: April

Owner/dealer info: Original owner's name/address removed for obvious privacy reasons.


*  The dates are counted from January 1, 1971
